MP Thermal Temperature Measurement Binocular Bullet Camera

2MP Thermal temperature measurement binocular bullet camera, based on Hisilicon embedded coding platform,integrated thermal imaging and visible light image sensors for temperature measurement. The maximum output resolution of the visible light sensor is 1920x1080@30fps, High accuracy. >>This product can support the advanced h. 265 Main profile encoding technology, achieve lower bit rate, HD picture quality. Support ONVIF、GB/T28181 etc. Network protocol, Standard SDK is available for quick integration.>> It can be widely used in close range scene monitoring,

Products Detail

Products Description

Model: T30
Thermal Temperature MeasurementBinocular Bullet Camera
2MP Thermal temperature measurement binocular bullet camera, based on Hisilicon embedded coding platform,integrated thermal imaging and visible light image sensors for temperature measurement. The maximum output resolution of the visible light sensor is 1920x1080@30fps, High accuracy. >>This product can support the advanced h. 265 Main profile encoding technology, achieve lower bit rate, HD picture quality. Support ONVIF、GB/T28181 etc. Network protocol, Standard SDK is available for quick integration.>> It can be widely used in close range scene monitoring,

Features

●Thermal imaging detector pixels 256x192
●1/2.8" 2.0M CMOS Sensor
●Maximum resolution 1920x1080@30fps
● Embedded deep learning algorithms, Support face snapshot function, can detect and capture 20 to 30 faces at the same time ●Support face tracking and scoring, More frames to identify, Automatic filtering output optimal face, and reduce repetitive capture ●Support H.265+ / H.265/ H.264 + MJPEG dual stream, three stream
●Support ONVIF, GB/T28181 etc. network protocol


Specifications

Thermal Module
Sensor
Silicon oxide uncooled focal plane detector
Resolution
256X192
Size
12μm
NETD
≤60mk @25℃,F#=1.0
Temperature Accuracy
Target Temperature 35℃~38℃;Temperature Accuracy±0.3℃
Target Temperature 20℃~33℃ or 38℃~50℃: Temperature Accuracy ±0.6℃
FOV
Horizontal:35° Vertical:27°
Image Mode
white heat, black heat, fusion, rainbow, iron red and other false color
Visible Light
Sensor
1/2.8”2.0M Pixel CMOS
Illumination
0.005Lux@F1.2(Color)、0.001Lux@F1.2(B/W)
WDR
≥80dB
S/N Ratio
≥46dB(AGC OFF)
Focus
4mm
FOV
Horizontal 84°、Vertical45°
AI
Face Capture
Embedded deep learning algorithms,Support face snapshot function,can detect and capture 20 to 30 faces at the same time. Support
face tracking and scoring,More frames to identify,Automatic filtering output optimal face,And reduce repetitive capture. Support
ONVIF、GB/T28181 etc. Network protocol.
Function
Measurement
Support global and regional temperature measurement
Alarm
High temperature limit/low temperature limit/area temperature difference alarm
Protocol
Support RTSP,RTP,TCP,UDP,UPNP,DHCP,PPPoE,ONVIF,GB/T 28181 protocol
Network Interface
1CH 10/100BaseT Ethernet,RJ45 port
Alarm Interface
Reserved
Voice Interface
Reserved
General
Operating Temps
-20℃~55℃
Operating Humidity
0%-90% RH(Non-condensing)
Protection class
IP67
Power Supply
12VDC
Consumption
≤5W(without heating)
Size
246mm*101mm*81mm
Weight
<1kg

Details Images
